NEEWER PS004E NP-F Battery Adapter Plate with NP-FZ100 Dummy Battery

Discounts Auto-Apply When You Cart It !

SKU: 66602800

All Neewer products carry a 2-Year Warranty and 45-day Return. Learn more at Warranty Policy.

Shipping Policy

Shipping from local warehouse based on your area, normally it takes 2~10 days for the delivery, Learn more at Shipping Policy.

Firmware & Manual

To download the product firmware or manual, please visit our Download Center.


  • Wide Compatibility- NEEWER PS004E Battery Adapter Plate suits all NP-F series batteries, including NP-F970, NP-F750, and NP-F550. While the NP-FZ100 Dummy Battery is compatible with Sony FX30 FX3 ZV-E1 a1 a9 a9 II a7S III a7R V a7R IV a7R III a7C a7 IV a7 III and a6600 cameras
  • Amplify Battery Power- PS004E Battery Adapter Plate can mount a high capacity NP-F battery on a camera cage via the 1/4¡± screw and provide sufficient power to your camera for outdoor shooting. NP-FZ100 dummy battery with a 5.5x2.1mm DC cable can connect to PS004E via the 7.4V output port
  • Dual DC Male Outputs- 7.4V male DC output port (5.5x2.1mm) and 12V male DC output port (5.5x2.5mm) can simultaneously distribute battery to a digital camera and a field monitor. Note: 12V DC cables (5.5x2.5mm) are sold separately
  • LED Battery Indicators- 4 LED power indicators inform you of the remaining battery level at >75%, >50%, >25%, and >5%

Battery Plate Adapter

  • Model: PS004E
  • Compatibility: NP-F series batteries
  • DC Output: 12V (5.5 x 2.5mm), 7.4V (5.5 x 2.1mm)
  • Output Current: 2A
  • Dimensions: 3.7¡± x 1.8¡± x 0.8¡± / 95 x 46 x 20mm
  • Weight: 3.3oz / 93g

Dummy Battery

  • Model: DR-FZ100
  • DC Connector: 7.4V (5.5 x 2.1mm)

Package Contents

  • 1 x PS004E NP-F Battery Adapter Plate
  • 1 x NP-FZ100 Dummy Battery with 5.5x2.1mm DC Cable
  • 1 x User Manual

NOTE: (1) NP-F batteries are not included. (2) Please insert NP-FZ100 Dummy Battery into the 7.4V output port. (3) The NP-FZ100 Dummy battery is not a real battery and cannot power your camera directlyC
